IP801B605S
8MP Smart Dual Illumination Fixed-focal Bullet Network Camera
8-MP 1/2.8" CMOS image sensor, low luminance, and high definition image. Outputs max. 8 MP (3840 × 2160) @20 fps, and supports 3072×2048 (3072 × 2048) @25/30 fps.. H.265 codec, high compression rate, ultra-low bit rate. Built-in warm light and IR LED, the max. IR light distance is 30 m and max. warm light is 20 m. ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments. Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes. Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human). Abnormality detection: Motion detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection. supports max. 128 GB Micro SD card; built in MIC. 12 VDC/PoE power supply, easy for installation. IP67, IK10 (optional) protection.
Features:
•High quality image with 8MP, 1/2.8"CMOS sensor
•8MP(3840*2160)@20fps,3072*2048/2592*1944/2560*1440/2304*1296/1080P/720P,Max 30fps ;
•Ultra 265+, H.265, H.264, MJPEG
•Smart IR, up to 30m (98ft) IR distance
• White Light, up to 30m (98ft) white light distance
• Built-in Mic & Speaker
•Supports 128 G Micro SD card
•IP67 protection
•Support PoE power supply
Specification：
| IP801B605S | ||||||||
| Camera | ||||||||
| Sensor | 1/2.8", 8.0 megapixel, progressive scan, CMOS | |||||||
| Lens | 2.8mm@F1.6 | 3.6mm@F1.6 | ||||||
| DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) | |||
| 2.8 | 43.4 | 17.4 | 8.7 | 4.3 | ||||
| 4.0 | 62.1 | 24.8 | 12.4 | 6.2 | ||||
| Angle Of View (H) | 106.7° | 87.5° | ||||||
| Angle Of View (V) | 57.1° | 46.3° | ||||||
| Angle Of View (O) | 115.7° | 92.4° | ||||||
| Adjustment Angle | Pan: 0° ~ 360° | Tilt: 0° ~ 90° | Rotate: 0° ~ 360° | |||||
| Shutter | Auto/Manual, 1 ~ 1/100000s | |||||||
| Minimum Illumination | Colour: 0.002Lux ( F1.6, AGC ON) 0Lux with light | |||||||
| Day/Night | IR-cut filter with auto switch (ICR) | |||||||
| Digital Noise Reduction | 2D/3D DNR | |||||||
| S/N | >52dB | |||||||
| IR Range | Up to 30m (98ft) IR range | |||||||
| White Light Range | Up to 30m (98ft) white light range | |||||||
| Wavelength | 850nm | |||||||
| IR On/Off Control | Auto/Manual | |||||||
| Defog | Digital Defog | |||||||
| WDR | 120dB | |||||||
| Video | ||||||||
| Video Compression | Ultra 265+, H.265, H.264, MJPEG | |||||||
| H.264 Code Profile | Baseline profile, Main profile, High profile | |||||||
| Frame Rate | Main Stream:8MP(3840*2160)@20fps,3072*2048/2592*1944/2560*1440/2304*1296/1080P/720P,Max 30fps; Sub Stream: 720*480/D1/VGA/640*360, Max 30fps; | |||||||
| Video Bit Rate | 128 Kbps~6 Mbps | |||||||
| 9:16 Corridor Mode | Supported | |||||||
| OSD | Up to 4 OSDs | |||||||
| Privacy Mask | Up to 4 areas | |||||||
| ROI | Up to 8 areas | |||||||
| Motion Detection | Up to 4 areas | |||||||
| Image | ||||||||
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 | |||||||
| Digital Noise Reduction | 2D/3D DNR | |||||||
| Smart IR | Supported | |||||||
| Flip | Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise | |||||||
| Dewarping | N/A | |||||||
| HLC | Supported | |||||||
| BLC | Supported | |||||||
| Audio | ||||||||
| Audio Compression | G.711 | |||||||
| Two-way Audio | Supported | |||||||
| Suppression | Supported | |||||||
| Sampling Rate | 8KHZ | |||||||
| Storage | ||||||||
| Edge Storage | Micro SD, up to 128GB | |||||||
| Network | ||||||||
| Protocols | HTTP/RTSP/DHCP/NTP/ONVIF/P2P | |||||||
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API | |||||||
| Client | LMS | |||||||
| Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below | |||||||
| Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ | ||||||||
| Interface | ||||||||
| Network | 10/100M Base-TX Ethernet | |||||||
| Built-in Mic | Supported | |||||||
| Built-in Speaker | Supported | |||||||
| Certifications | ||||||||
| Certifications | CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 | |||||||
| General | ||||||||
| Power | DC 12V±25%, PoE (IEEE 802.3af) | |||||||
| Power consumption: Max 9.0W | ||||||||
| Dimensions(L × W × H) | 191×75×74mm (7.5”×2.9”×2.9”) | |||||||
| Net Weight | 0.41kg (0.90lb) | |||||||
| Material | Metal | |||||||
| Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) | |||||||
| Strorage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) | |||||||
| Surge Protection | 4KV | |||||||
| Ingress Protection | IP67 | |||||||
